Issue :

We often come across a scenario in which MRP0 process stop applying logs and the status of it will be WAIT_FOR_LOG.

Workaround :

Check LNS on Primary Database: Writing

SQL> select inst_id, process, status, thread#, sequence#, block#, blocks from gv$managed_standby where process in ('RFS','LNS','MRP0');

INST_ID PROCESS STATUS THREAD# SEQUENCE# BLOCK# BLOCKS
---------- --------- ------------ ---------- ---------- ---------- ----------
2 LNS WRITING 2 74 17873 1
1 LNS WRITING 1 79 24255 1

LNS Process :

In Data Guard, LNS process performs actual network I/O and waits for each network I/O to complete.

The NET_TIMEOUT attribute is used only when the LGWR process transmits redo data using a LGWR Network Server(LNS) process.

Check MRP0 on Standby Database: WAIT_FOR_LOG

SQL> select inst_id, process, status, thread#, sequence#, block#, blocks from gv$managed_standby where process in ('RFS','LNS','MRP0');

INST_ID PROCESS STATUS THREAD# SEQUENCE# BLOCK# BLOCKS

2 RFS IDLE 0 0 0 0
2 RFS IDLE 0 0 0 0
2 RFS IDLE 0 0 0 0
2 RFS IDLE 1 79 25361 1
2 RFS IDLE 0 0 0 0
2 RFS IDLE 0 0 0 0
2 MRP0 WAIT_FOR_LOG 2 74 0 0

Check Broker Status

Check the apply lag by the broker.

Database - standb

Role: PHYSICAL STANDBY
Intended State: APPLY-ON
Transport Lag: 0 seconds
Apply Lag: 2 hour(s) 55 minutes 47 seconds
Real Time Query: OFF
Instance(s):
standb1
standb2 (apply instance)

Database Status:
SUCCESS

Apply Lag: We can clearly see the difference of 2 hour(s) 55 minutes 47 seconds

Re-enable Standby Database

DGMGRL> enable database standb;
Enabled.

Now check the status again.

SQL> select inst_id, process, status, thread#, sequence#, block#, blocks from gv$managed_standby where process in ('RFS','LNS','MRP0');

INST_ID PROCESS STATUS THREAD# SEQUENCE# BLOCK# BLOCKS
---------- --------- ------------ ---------- ---------- ---------- ----------
1 RFS RECEIVING 0 0 0 0
2 RFS IDLE 0 0 0 0
2 RFS IDLE 0 0 0 0
2 RFS IDLE 0 0 0 0
2 RFS IDLE 1 80 58 1
2 RFS IDLE 0 0 0 0
2 RFS IDLE 0 0 0 0
2 MRP0 APPLYING_LOG 1 79 24581 25582

Now it’s back to normal. APPLYING_LOG is the normal status for real-time applying service.
